LEAD GLASS - RADIATION PROTECTION GLASS

 PRODUCTS







LEAD GLASS



















>>






Our company is the largest  supplier of RD50 lead glass in the Southeast European region. Providing radiation protection glass to projects through a network of local dealers.











Optimal radiation protection

If radiation penetrates the human tissue, there is a risk of damage to tissue and organs. Radiation Shielding Glasses RD 50 and RD 30 provide optimum protection, as they contain a high percentage of lead oxide, absorbing the rays.

The figure "50" stands for a min. 5,05 g/cm³ density.
The figure "30" stands for a min. 3,13 g/cm³ density.

The Radiation Shielding Glasses RD 50® and RD 30® provide the best protection for:

  • Technicians monitoring the x-ray process in medicine and industry
  • Technicians at mammography work stations
  • Technicians in research and development (i.e. "glove-box")

RD 50®   Most used lead equivalents are given on the following table.

The type of Radiation Shielding Glass to use depends on the dose of radiation.




glass thickness-   mm  Lead equivalent (110 kilovolt) max size mm

3.5 - 5.0

1.1 mm Pb

600x1300
5.0 - 6.5 1.6 mm Pb 1000x1700
7.0 - 8.5 2.2 mm Pb 1050x2100
8.5 -10.0  2.7 mm Pb 1050x2100
10.0 - 11.5 3.2 mm Pb 1000x2000
11.5 - 13.0 3.7 mm Pb 1000x2000
16.0 - 18.0 5.1 mm Pb 800x1500
20.0 - 22.0 6.4 mm Pb 800x1500

                 Short  delivery time of standard sizes from local inventory.

Small glass thickness

RD 50® provides high radiation absorption with a small glass thickness

Insulated glass

RD 50® / RD 30® can be processed to insulated glass

Laminated glass

Both RD 50® and RD 30® can be processed as laminated safety glass.











An application in Germany using RD50 lead glass





Packaging for export.
